Samsung Electronics 2-1
2. Product Specifications
2-1 Product Specifacations
*1) Mode
- HP : Heat Pump, HR : Heat Recovery
*2) Nominal cooling capacities are based on;
- Indoor temperature : 27˚C DB, 19˚C WB
- Outdoor temperature : 35˚C DB, 24˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*3) Nominal heating capacities are based on;
- Indoor temperature : 20˚C DB, 15˚C WB
- Outdoor temperature : 7˚C DB, 6˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*4) Sound pressure was acquired in a dead room. Thus actual noise level may be different depending on the installation conditions.
*5) Specifications may be subject to change without prior notice for product improvement.
Model AM022FN1DEH/TK AM028FN1DEH/TK AM036FN1DEH/TK
Power Supply ø/V/Hz 1/220~240/50 1/220~240/50 1/220~240/50
Mode*
1)
HP / HR HP / HR HP / HR
Performance
Capacity
Cooling*
2)
kW 2.2 2.8 3.6
Btu/h 7,500 9,500 12,200
Heating*
3)
kW 2.6 3.2 4.0
Btu/h 8,500 10,900 13,600
Condensate (with High fan speed) Liters/h 1.12 1.44 1.6
Power
Input W 50*
5)
45*
5)
50*
5)
Running Current A 0.20*
5)
0.23*
5)
0.25*
5)
Sound Level Sound Pressure*
4)
dB(A) 34 37 40
Fan
Type - Crossflow fan Crossflow fan Crossflow fan
Motor
Model - Y4S476B041L Y4S476B041L Y4S476B041L
Type - Feedback SSR Feedback SSR Feedback SSR
Output W - - -
Air Flow Rate m
3
/min 6/5/4
7/6/5 8/7/6
Refrigerant
Type - R410A R410A R410A
Control Method - EEV EEV EEV
Temperature Control - Micom & Thermistors Micom & Thermistors Micom & Thermistors
Safety Devices - Fuse Fuse Fuse
Piping
Connections
Liquid (Flare) ø, mm 6.35 6.35 6.35
Gas (Flare) ø, mm 12.7 12.7 12.7
Drain (Quick Lock) ø, mm VP20 (OD 25, ID 20) VP20 (OD 25, ID 20) VP20 (OD 25, ID 20)
Weight
Net Weight kg 10.5 10.5 10.5
Shipping Weight kg 13.0 13.0 13.0
Dimensions
Net Dimensions (W x H x D) mm 970x135x410 970x135x410 970x135x410
Shipping Dimensions (W x H x D) mm 1,164x212x478 1,164x212x478 1,164x212x478
Panel Size
Model - PC1NUSMAN PC1NUSMAN PC1NUSMAN
Net Weight kg 3.0 3.0 3.0
Shipping Weight kg 5.0 5.0 5.0
Net Dimensions (W x H x D) mm 1,180x25x460 1,180x25x460 1,180x25x460
Shipping Dimensions (W x H x D) mm 1,259x144x539 1,259x144x539 1,259x144x539
Functions
Auto Restart - O O O
Auto Swing - O O O
Group/Individual Control - O O O
External Contact Control - O O O
Trouble Shooting by LED - O O O
Standard
Accessories
Installation Manual - O O O
Operation Manual - X X X
Pattern Sheet for Installation - O O O
Flexible Drain Hose - O O O
Filter / Safety Grille - Filter (Washable) Filter (Washable) Filter (Washable)
Drain Pump (Pumping speed, lift) /h,mm 24, 750 24, 750 24, 750
Optional
Accessories
Wireless Remote Controller - MR-DH00 MR-DH00 MR-DH00
Wired Remote
Controller
- MWR-WE10N MWR-WE10N MWR-WE10N
External Contact Interface Module - MIM-B14 MIM-B14 MIM-B14
2-1-1 Indoor Unit
QSlim 1way cassette type
