3-2 Samsung Electronics
No Parts Procedure Remark
1 Panel & Filter
(A type)
1) Press the Push Button on the Grill and
open it
2) Separate 1 clip from the Panel and tilt
the Grill to 45° and separate the Grille
from the Panel.
3) Separate the Filter from the Panel.
4) Separate 3 cover screws from it.
5) Unscrew 6 fixed screws and
separate them from the Indoor Unit.
(Use +Screw Driver)
3-1 Indoor Unit
QSlim 1 way cassette type (medium)
To Next Page
