6.2 OPERATION AND ATTENDANCE
Machine safety protection
The mowing machine is equipped with safety contacts which are closed by:
- switch placed under the seat
- switch of the grass collecting bin suspending, contingently of the deflector
- switch of the grass collecting bin fill-up
- switch of the travel pedal
The engine will automatically stop if the driver leaves the seat. The engine can only be started up if the mowing mechanism is switched off and the grass
collecting bin is suspended, contingently the deflector, which prevents from the entering of the mowed grass into the inlet tunnel of the collecting bin
during mulching, is put in.
6.2.1 SUSPENSION OF GRASS COLLECTING BIN
Grasp the grass collecting bin with both hands and lift it. Tilt it to be reclined under the angle of 40° and suspend it on two brackets located on the
machine rear side. The tops of labels having the shape of yellow triangles must be opposite one to the other (see the chapter 4.2.7).
6.2.2 ENGINE STARTING
• Check the petrol level in the tank.
• Open the petrol supply closure - valid only for the BS15 engines having power output of 15,5 HP
• Sit down onto the machine seat comfortably, shift the mowing mechanism height setting-up lever 6.1.17 to the position "7".
• Set the mowing mechanism switch
6.1.1 to the "OFF" position.
•
Caution, do not step on the travel pedal 6.1.14.
• Set the gas control lever 6.1.3 to the "MAX“ position - only at machines with engine having power output of 16 HP and higher.
• Set the gas control lever
6.1.3 to the "CHOKE“ position - only at machines with the BS15 engines having power output of 15,5 HP.
• Pull out the choke
6.1.4 - only at machines with engine having power output of 16 HP and higher.
• Do not manipulate the mowing mechanism height setting up lever
6.1.17.
• Turn the ignition key 6.1.2 to the "START“ position.
The time of starting must not exceed 10 seconds – if this time is exceeded a damage to the battery threatens.
• The engine "is running" - let loose the ignition key. The key will automatically return to the "ON" position.
• Progressively push the choke 6.1.4 inwards - only at machines with engine having power output of 16 HP and higher.
• Set the gas control lever 6.1.3 slowly to the "MIN" position (reduce the engine speed).
• Let the engine run for several minutes before turning on the mowing mechanism.
6.2.3 ENGINE STOPPING
• Set the gas control lever 6.1.3 to the "MIN" position.
• Turn off the mowing mechanism by the switch
6.1.1 (see the chapter 6.2.4).
• If the engine is overheated, let it running for a while at minimum revolutions.
•
Turn off the engine by the key 6.
1.2
r
otation to the "STOP" position and remove the key from the ignition.
6.2.4 MOWING MECHANISM TURNING ON AND OFF
a) Turning on
• Set the gas control lever 6.1.3 to the "MAX" position.
• Set the working position of the mowing mechanism and with it also the height of mowing by the mowing mechanism height setting-up lever (see the
chapter 6.1.17 and 6.2.5).
•
Se
t the mo
wing mechanism swit
ch
6.
1
.
1
t
o the "ON" position.
The mowing mechanism will be switched on provided:
-
operator is sitting on the machine seat
-
grass collecting bin is suspended, contingently the deflector is put in
- AUT/MAN switch
6.1.9 is in the "AUT" position, and the "RESET" switch 6.1.10 was depressed after discharging the grass collecting bin - valid
only f
or models eq
uipped with the A
UT/MAN swit
ch
- AUT/MAN switch
6.1.9 is in the "MAN" position - valid only for models equipped with the AUT/MAN switch
b) Turning off
•
Se
t the mowing mechanism switch
6.
1
.1
t
o the "OFF" position.
• If the driver leaves the seat, the engine will stop automatically, and with this also the rotation of mowing knives.
18
DANGER !
Never leave the running engine in a closed or badly ventilated room. The exhaust fumes containing the carbon monoxide are very dangerous.
Keep Your hands, legs and loose clothes out of the reach of moving parts and of the exhaust.
W
ARNING !!!
Never stop the engine by a mere getting off the seat, as the key left in the ignition switch may cause a fault of the electrical installation.
Always rotate the key to the "OFF" position and remove it from the switch box.
IMPOR
TANT
Bef
or
e turning the ignition off, reduce the engine revolutions to the slow speed in case the self-ignition will occur,
not observing this instruction may result in a damage to the engine and exhaust.
WARNING !!!
Never switch off the mowing mechanism by mere getting off the seat. Unless You switch over the ignition key from the "ON" position
to the "OFF" (STOP) position, the part of the electrical installation is still live and this may cause its fault.
