LOGO! Manual
A5E00067781 01
138
6.1 Overview of the Modules
Yellow program module
You can read and write programs with this module.
Red program module
You can only write programs with this module. Once a pro-
gram has been stored, it cannot be looked at, copied or
changed (i.e. your data is protected).
Programs saved like this can only be run if the module re-
mains inserted in LOGO! while the system is in operation.
!
Warning
Make sure that you don’t save your program on
a module with program protection if you intend to
edit it further.
You can start up a program on a module with
know-how protection but not read it for the pur-
pose of editing.
LOGO! Pro
g
ram Modules

Siemens LOGO! 230RC Specifications

General

Inputs	8 digital inputs
Outputs	4 relay outputs
Mounting Type	DIN rail
Protection Type	IP20
Dimensions	90 x 72 x 55 mm
Output Current	10 A
Operating Temperature	0°C to 55°C
Power Supply	115/230V AC
Storage Temperature	-40°C to +70°C
