Siemens LOGO! 230RC User Manual

217
LOGO! Manual
A5E00067781 01
F LOGO! Menu Structure
LOGO:
Active
Passive
Active
n times
message
texts
n = 0..5
>Program..
>PC/Card..
>Start
>ASi_Bus..
>Set Clock
>Clear Prg
>Edit Prg
Clear Prg
No
Yes
Set Clock
#
I:12345678
9 10 11 12
Q:12345678
We 08:44
ASi_Bus
Ia : 1234
Qa : 1234
Bus: Off
We 08:31
MM.DD.YY
01.11.00
#
PC<->LOGO
Stop?
Press ESC
Q1
>Card->LOGO
>LOGO->Card
>PC<->LOGO
= optional menus

Siemens LOGO! 230RC Specifications

General

Inputs	8 digital inputs
Outputs	4 relay outputs
Mounting Type	DIN rail
Protection Type	IP20
Dimensions	90 x 72 x 55 mm
Output Current	10 A
Operating Temperature	0°C to 55°C
Power Supply	115/230V AC
Storage Temperature	-40°C to +70°C
