Siemens LOGO! 230RC User Manual

LOGO! Manual
A5E00067781 01
36
3.4 The 4 Golden Rules for Working with
LOGO!
Rule 1
3-finger grip
 Enter the circuit in programming mode. Switch to pro-
gramming mode by pressing the 3 keys , and OK at
the same time.
 Change the values of times and parameters in parame-
terization mode. Switch to parameterization mode by
pressing the 2 keys ESC and OK at the same time.
Rule 2
Outputs and inputs
 Always enter a circuit from output to input.
 You can connect an output to several inputs, but not
several outputs to one input.
 You can’t connect an output to a preceding input within
a program path. Insert markers or outputs in such cases
(recursions).
Pro
g
rammin
g
LOGO!

Siemens LOGO! 230RC Specifications

General

Inputs	8 digital inputs
Outputs	4 relay outputs
Mounting Type	DIN rail
Protection Type	IP20
Dimensions	90 x 72 x 55 mm
Output Current	10 A
Operating Temperature	0°C to 55°C
Power Supply	115/230V AC
Storage Temperature	-40°C to +70°C
