A.8 Technical Specifications:
LOGO! Contact 24/230
LOGO! Contact 24 and LOGO! Contact 230 are switching
modules for the direct switching of ohmic loads of up to 20
A and motors of up to 4 kW (without noise emission, hum–
free).
LOGO!
Contact 24
LOGO!
Contact 230
Operating voltage 24 V DC 230 V AC;
50/60 Hz
Switching capacity
Utilization category AC-1: Switching of
ohmic load at 55°C
Operating current at 400 V
Output of three–phase loads at 400 V
85 ... 264 V
(derating at <93 V)
20 A
13 kW
Utilization category AC-2, AC-3: Motors
with slipring or squirrel–cage rotor
Operating current at 400 V
Output of three–phase loads at 400 V
85 ... 264 V
(derating at <93 V)
8.4 A
4 kW
Short–circuit protection:
Assignment type 1
Assignment type 2
25 A
10 A
Connecting leads Finely stranded with wire end fer-
rules
single–core
2x (0.75 to 2.5) mm
2
2x (1 to 2.5) mm
2
1 x 4 mm
2
Dimensions (WxHxD) 36 x 72 x 55
Ambient temperature -25 ... +55°C
Storage temperature -50 ... +80°C
