179
LOGO! Manual
A5E00067781 01
8.6.3 Fluorescent Luminaire Control with
LOGO! 230RC
L1N I1I2I3I4I5I6
Q1 Q2 Q3 Q4
SIEMENS
L1
N
E2 E3 E4
B1
lx<
Fluorescent
lamp 1
E5
Fluorescent
lamp 2
Fluorescent
lamp 3
Fluorescent
lamp 4
S1 S2 S3 S4
LOGO! 230RC
Components used
S1 to S4
(NO contact)
Switches
B1
(NO contact)
Daylight control switch
