Siemens LOGO! 230RC User Manual

39
LOGO! Manual
A5E00067781 01
3.6 Entering and Starting a Program
You have designed a circuit and now want to enter it in
LOGO!. The example below illustrates how to do this.
3.6.1 Switching to Programming Mode
Connect LOGO! to the mains and switch on the power. The
following message appears on the display:
No Program
Switch LOGO! to programming mode To do this, press the
keys , and OK at the same time. The fact that you have
to press the keys simultaneously prevents anyone pressing
them and switching to programming mode inadvertently.
No Program
When you press the keys, LOGO!’s main menu appears:
>Program..
PC/Card..
Start
LOGO!’s main menu
On the left in the first line you will see ”>”. Use the keys
and to move the ”>” up and down. Move the ”>” to
”Program..” and press OK. LOGO! switches to the pro-
gramming menu.
Pro
g
rammin
g
LOGO!

Siemens LOGO! 230RC Specifications

General

Inputs	8 digital inputs
Outputs	4 relay outputs
Mounting Type	DIN rail
Protection Type	IP20
Dimensions	90 x 72 x 55 mm
Output Current	10 A
Operating Temperature	0°C to 55°C
Power Supply	115/230V AC
Storage Temperature	-40°C to +70°C
