Siemens SIMATIC IPC427D User Manual

Technical specifications
8.6 Hardware descriptions
SIMATIC IPC427D
Operating Instructions, 05/2017, A5E31347215-AB
123
8.6.1.2
CFast card
Pin assignment for the CFast card interface
Pin no.
Short description
Meaning
S1
SGND
Signal GND (ground for signal integrity)
S2
A+
SATA differential
S3 A- SATA differential
S4
SGND
Signal GND (ground for signal integrity)
S5
B-
SATA differential
S6
B+
SATA differential
S7
SGND
Signal GND (ground for signal integrity)
PC1
CDI
Card Detect Out
PC2
GND
Device GND
PC3
TBD
TBD (not connected)
PC4
TBD
TBD (not connected)
PC5
TBD
TBD (not connected)
PC6
TBD
TBD (not connected)
PC7
GND
Device GND
PC8
LED1
LED Output (not connected)
PC9
LED2
LED Output (not connected)
PC10
IO1
Reserved Input/Output (not connected)
PC11
IO2
Reserved Input/Output (not connected)
PC12
IO3
Reserved Input/Output (not connected)
PC13
PWR
Device Power (3.3V)
PC14
PWR
Device Power (3.3V)
PC15 GND Device GND
PC16
GND
Device GND
PC17 CDO Card Detect In
