Technical specifications
8.7 BIOS description
SIMATIC IPC427D
164 Operating Instructions, 05/2017, A5E31347215-AB
8.7.10
Default BIOS Setup entries
Documenting your device configuration
If you have changed any default settings in Setup, you can enter them in the following table.
You can then refer to these entries for any future hardware modifications.
Note
Print out the table below and keep the pages in a safe place once you made you
r entries.
BIOS Setup default settings
System parameters
Defaults
Custom entries
Main
System Time
hh:mm:sss
System Date
MM/DD/YYYY
Advanced
HPET – HPET support
Auto
Boot configuration
Numlock
On
Peripheral Configuration
Internal COM 1
Auto
Base I/O address
3F8
Interrupt
IRQ4
Internal COM 2
Auto
Base I/O address
2F8
Interrupt
IRQ3
PCI - MPI/DP
1)
Enabled
Profinet
4)
Enabled
CAN
2)
Auto
Base I/O address
2)
5400
Interrupt
IRQ5
Azalia internal HDMI codec
Enabled
On-board Ethernet 1
Enabled
Ethernet 1 Address
00:1B:1B:41:42:7B
Onboard Ethernet 2
3)
Enabled
Ethernet 2 address
3)
00:1B:1B:0A:85:10
1)
Only for devices with PROFIBUS
2)
Only for devices with CAN bus
3)
Not for devices with PROFINET
4)
Only for devices with PROFINET
