Mounting and connecting the HMI device
4.3 Mounting the device
SIMATIC IPC477E PRO
Operating Instructions, 08/2017, A5E39912462-AA
35
Prepared for support arm or stand without extension elements (flange on top)
Note
Mounting without base adapter
If you install the device without a base adapter, you must adjust the mechanical interface
between the support arm or pedestal and
the unit accordingly, including placement of an
appropriate seal on the mechanical interface of the device.
● All packaging components and protective films have been removed.
● Siemens base adapter with screws (supplied with the device version "prepared for
support arm without extension components (flange at top)" and "prepared for
pedestal/extension components (flange at bottom)").
● One of the following support arms or pedestal systems:
– Support arm or pedestal with mechanical VESA interface and the corresponding
Siemens adapter set
– Support arm or pedestal with mechanical interface for the Siemens base adapter
The type of mechanical interface differs depending on the type of support arm or
pedestal.
See section "System components (Page 15)"
● The following cables are fed through the pedestal or the support arm to which the device
is mounted:
– Protective conductor
– Power supply cable
– Data cables, e.g. USB
For even large connectors to fit, run their cables through the pedestal or support arm
first.
