Operating the device and device functions
6.3 IPC Wizard functions
SIMATIC IPC477E PRO
62 Operating Instructions, 08/2017, A5E39912462-AA
Functions of the multi-touch screen
General functions
● Detection of up to 5 finger touches at a time.
● Detection of gestures that are supported by the operating system or the software installed
on the device.
-touch operation can
provide advanced features or pose limitations depending on the
operating system and the software installed on the device. Read the corresponding
documentation.
● You do not need to calibrate the touch screen. Some operating systems do offer touch
calibration. However, this calibration does not result in increased accuracy.
Security functions in an industrial environment
The touch screen is locked for security reasons when following happens:
● There is a conductive liquid on the touch screen with ground contact via the enclosure or
the operator, for example.
● Electromagnetic interference is present that exceeds the specification according to EN
61000-4-2.
Once the interference is over, the touch screen is no longer locked.
IPC Wizard functions
Software components
● General for all devices: Panel PC Tools
– SetBrightness
– IPCScreenSaver
All other functions are described in the manual "SIMATIC IPC Wizard 2.1 and Panel
Configuration Center":
● On the supplied USB stick
● In the IPC Wizard installation directory on the PC
