Siemens SIMATIC IPC477E PRO User Manual

Maintaining and repairing the device
8.5 Installing the software
SIMATIC IPC477E PRO
98 Operating Instructions, 08/2017, A5E39912462-AA
8.5.2
Partitioning the data storage medium
8.5.2.1
Partitioning in Windows Embedded Standard 7
You will need to reconfigure the partitions after installing a new drive, to repair corrupt
partitions or to change the partitioning.
Partitioning of the SIMATIC IPC CFast card
The SIMATIC IPC CFast card for Windows Embedded Standard 7 comes configured with
the following default partitions:
Table 8- 1 32-bit version of the operating system
Partition
Name
Size of the card
File system
8 GB
16 GB
30 GB
First SYSTEM 6 GB 12 GB 30 GB NTFS (not compressed)
Second DATA Re-
mainder
Re-
mainder
Re-
mainder
NTFS (not compressed)
* Due to partitioning/formatting, the actual CFast capacity does not correspond to the
memory size specified on the SIMATIC IPC CFast card.
Table 8- 2 64-bit version of the operating system
Partition
Name
Size of the card
File system
8 GB
16 GB
30 GB
First
SYSTEM
7 GB
12 GB
30 GB
NTFS (not compressed)
Second DATA Re-
mainder
Re-
mainder
Re-
mainder
NTFS (not compressed)
* Due to partitioning/formatting, the actual CFast capacity does not correspond to the
memory size specified on the SIMATIC IPC CFast card.
Partitioning of the SSD
The following partitions are configured in the delivery state of the SSD with Windows
Embedded Standard 7:
Partition
Name
Size of data medium
File system
>100 GB
>100 GB
Primary
SYSTEM
60 GB
100 GB
NTFS not compressed
Second
DATA
Remainder
Remainder
NTFS not compressed
To restore the partitions to their original delivery state, we recommend you use the software
SIMATIC IPC Image & Partition Creator.
Additional information is available in the
accompanying documentation.
