Setting Up and Operating the SIMATIC Rack PC IL 40 S
3-3
SIMATIC Rack PC IL 40 SManual
A5E00200171-01
3.2 Installing the Rack PC
The Rack PC is suitable for vertical and horizontal fitting in consoles, switch boards
and 19” rack systems.
The Rack PC meets the requirements for a fire enclosure to EN60950. It can
therefore be fitted without an additional fire enclosure.
Please note the following points when installing the PC:
• Avoid extreme ambient conditions as far as possible. Protect your PC from
dust, moisture, and heat.
• Keep the PC out of direct sunlight.
• Mount the PC as safely as possible to prevent any danger (for example, by
falling over).
• The clearance near the ventilation slots must be at least 50 mm, so that the PC
is sufficiently ventilated.
• Make certain that the ventilation slots for the housing are not covered.
• The device is meets the protection class IP30 requirements on the front side.
Ensure that opening for the Rack PC is protected against water in an
environment where there is a risk of splashing water.
• Make certain that the sliding door in front of the drives is closed during
operation.
• The Rack PC can be mounted on telescopic rails or on cabinet brackets. It is
not permitted to mount it at the 19” front supports only.
• Use the respective manufacturer’s cabinet or rack slide rails or L-sections.
Contact your cabinet supplier directly regarding cabinet or rack installation.
• The use of the telescopic rails makes it possible to completely pull the Rack PC
out of the cabinet or rack.
!
Warning
If the systems are installed without keeping to the conditions mentioned above, the
approvals pursuant to UL 508 and EN60950 are no longer valid!
