SIMATIC Rack PC IL 40 S Expansions
4-6
SIMATIC Rack PC IL 40 SManual
A5E00200171-01
4.1.4 Components Visible after Opening the Unit
Components
Once you have removed the housing cover of your unit, following components are
visible:
1 Motherboard
2 Modules slots (6x PCI, 1x AGP)
3 Device for holding down the modules
4 Module groove
5 Fan
6 Drive support module
7 Support plate
8 Hard disks
9 Power supply
1
3
4
5
6
7
8
9
2
Figure 4-4 Rack PC Open
