Parts for SIMOTION D410 Order No. Accessor
ies
Spare part
CompactFlash card 1 GB
Latest CF card at the time of writing
6AU1400-2PA03-0AA0 x -
Terminal kit, contains
●
2 x I/O connectors for X120/X121
● 1 x 24 V connector for X124
● 1 x DRIVE-CLiQ blanking cover for X100
6SL3064-8LA00-0AA0 - x
Plug connector for power supply (X124) 6SL3065-2AA00-0AA0 - x
Blanking cover 6SL3064-3BB00-0AA0 - x
Plug connector for PROFIBUS interface up to 12 Mbit/s, 90° cable outlet:
Without PG socket without FastConnect insulation displacement 6ES7972-0BA12-0XA0 x -
Without PG socket with FastConnect insulation displacement 6ES7972-0BA50-0XA0 x -
With PG socket without FastConnect insulation displacement 6ES7972-0BB12-0XA0 x -
With PG socket with FastConnect insulation displacement 6ES7972-0BB50-0XA0 x -
Plug connector for PROFIBUS interface up to 12 Mbit/s, angular cable outlet:
Without PG socket without FastConnect insulation displacement 6ES7972-0BA42-0XA0 x -
Without PG socket with FastConnect insulation displacement 6ES7972-0BA60-0XA0 x -
With PG socket without FastConnect insulation displacement 6ES7972-0BB42-0XA0 x -
With PG socket with FastConnect insulation displacement 6ES7972-0BB60-0XA0 x -
Connector for PROFINET interface
RJ45 plug connector, IE FC RJ45 Plug 180
1 pack = 1 unit 6GK1901-1BB10-2AA0 x -
1 pack = 10 units 6GK1901-1BB10-2AB0 x -
1 pack = 50 units 6GK1901-1BB10-2AE0 x -
FastConnect cables for Industrial Ethernet / PROFINET
● IE FC standard cable GP 2x2 6XV1840-2AH10 x
● IE FC flexible cable GP 2x2 6XV1870-2B x
● IE FC trailing cable GP 2x2 6XV1870-2D x
● IE FC trailing cable 2x2 6XV1840-3AH10 x
● IE FC marine cable 2x2 6XV1840-4AH10 x
Stripping tool for Industrial Ethernet / PROFINET FastConnect cables
● IE FC Stripping Tool 6GK1901-1GA00 x
To obtain order data information for other SINAMICS drive components, such as Line Modules,
Motor Modules, DRIVE-CLiQ cables, etc., see the
PM 21
Catalog.
Note
If
the fan for the SIMOTION D410 is defective, it can be replaced. The procedure for replacing
the SIMOTION D410 fan is described in the
SIMOTION D410
Commissioning Manual.
Spare parts/Accessories
8.7 List of spare parts and accessories
SIMOTION D410
Manual, 04/2014 101
