Interface characteristics
Table 4-10
Ports X200 and X201
Characteristic Type
Connector type RJ45 socket connector
Cable type PROFINET
Maximum cable length 100 m
Minimum transmission cycle 0.5 ms
Autocrossing Yes
i.e. both crossed and uncrossed cables can be used
Interface assignment
Table 4-11
Assignment of ports X200 - X201
Representation Pin Name Description
1 TXP Transmit data +
2 TXN Transmit data -
3 RXP Receive data +
4 Reserved, do not use
5 Reserved, do not use
6 RXN Receive data -
7 Reserved, do not use
8 Reserved, do not use
Connectable devices
The following devices can be connected to the PROFINET interface:
● PG/PC
programming devices (communication with SIMOTION SCOUT / STEP 7 and HMI)
● SIMATIC HMI devices
● Distributed I/O
● Other SINAMICS drive units (e.g., CU310 PN or CU320 with CBE20)
See also
Connecting the PROFINET interface (D410 PN only) (Page 82)
4.6 Encoder interface (HTL/TTL/SSI)
The HTL/TTL/SSI encoder interface is used to connect external encoders.
Interfaces
4.6 Encoder interface (HTL/TTL/SSI)
SIMOTION D410
52 Manual, 04/2014
