NOTICE
Motor overheating due to an incorrectly connected KTY temperature sensor
A sensor connected with the incorrect polarity cannot detect the motor overheating.
Connect the KTY temperature sensor with the correct polarity.
For
more information on the temperature sensors and how to use them, see the
SINAMICS
S120
Commissioning Manual, in Chapter Temperature sensors for SINAMICS components.
Further information on the temperature sensors can be found in the following literature:
Literature:
/IH1/ SINAMICS S120, Commissioning Manual, Chapter "Temperature sensors for
SINAMICS components."
DANGER
Danger to life from electric shock due to insufficient safety isolation
Only temperature sensors that meet the safety isolation specifications stipulated in EN
61800-5-1 may be connected to terminals "+Temp" and "-Temp."
Use a Sensor Module External (SME120 or SME125) or Terminal Module TM120 if safe
electrical separation cannot be guaranteed (for linear motors or third-party motors, for
example), .
4.8 Power supply
SIMOTION D410 can be supplied with power by connecting a PM340 power module. In the
following situations, a 24 V DC load power supply must also be connected via X124:
● For supplying the digital outputs (X121)
● For the 24 V supply on the DRIVE-CLiQ cable (e.g. for DRIVE-CLiQ encoders that do not
have their own power supply)
● For supplying the motor holding brake
Interfaces
4.8 Power supply
SIMOTION D410
Manual, 04/2014 57
