Spare parts/Accessories
8
8.1 Terminal module TM31
Characteristics of the TM31
The
TM31 Terminal Module allows you to expand the number of available digital inputs/outputs
as well as the number of analog inputs/outputs within a drive system. The TM31 is connected
via DRIVE-CLiQ. It has 2 DRIVE-CLiQ interfaces for this.
The TM31 contains the following terminals:
Table 8-1 Interface overview of the TM31
Interface Quantity
Digital inputs 8
Bidirectional inputs/outputs 4
Relay outputs with changeover contact 2
Analog inputs 2
Analog outputs 2
Temperature sensor input (KTY84-130 or PTC) 1
NOTICE
Overheating if ventilation clearances are too small
Insufficient ventilation clearances result in overheating and therefore in more failures and a
shortened life of the component.
Maintain 50 mm ventilation clearances above and below the component.
Additional references
For further information on TM31, see the
SIMOTION D410
Commissioning Manual.
8.2 Terminal module TM41
Characteristics of the TM41
With the TM41 Terminal Module, the number of available digital inputs/digital outputs and the
number of analog inputs within a drive system can be expanded. In addition, it enables the
use of the TTL output for encoder simulation. The TM41 is connected via DRIVE-CLiQ. The
SIMOTION D410
Manual, 04/2014 95
