Type Quantity
Sensor
1)
power supply, no dynamization 1
Digital inputs for testing the F-DO during test stop 4
1)
Sensors:
Fail-safe devices for commanding and detecting, such as emergency stop pushbuttons and
safety locks as well as position switches and light arrays / light curtains.
2)
Dynamic response: The sensor power supply is switched on and off during test stop for testing the
sensors, the cable routing, and the evaluation electronics of TM54F.
The TM54F provides 4 fail-safe digital outputs and 10 fail-safe digital inputs. A fail-safe digital
output consists of a P/M-switching output as well as a digital input for reading back the switching
state. A fail-safe digital input is made up of two digital inputs.
NOTICE
Overheating if ventilation clearances are too small
Insufficient ventilation clearances result in overheating and therefore in more failures and a
shortened life of the component.
Maintain 50 mm ventilation clearances above and below the component.
Additional references
You
will find detailed information on the TM54F Terminal Module in the
SINAMICS S120 Safety
Integrated
Function Manual.
8.4 Terminal modules TM15 and TM17 High Feature
Features of TM15 and TM17 High Feature
The TM15 and TM17 High Feature Terminal Modules are used to implement inputs of
measuring inputs and outputs of output cams for SIMOTION D. In addition, these Terminal
Modules provide drive-related digital I/Os with short signal delay times. TM15 and TM17 High
Feature are connected via DRIVE-CLiQ.
TM15
Each of the 24 electrically isolated digital I/Os can be parameterized channel-by-channel as
a digital input (DI), digital output (DO), a measuring input input, or an output cam output.
TM15 DI/DO
Each of the 24 isolated digital I/Os can be configured on a channel-specific basis as a digital
input (DI) or digital output (DO). The digital I/Os can be interconnected using BICO technology
Spare parts/Accessories
8.4 Terminal modules TM15 and TM17 High Feature
SIMOTION D410
Manual, 04/2014 97
