Digital inputs
4 digital inputs are available on the control unit.
The electrically isolated inputs can be used as freely addressable inputs.
Switches or proximity encoders (2- or 3-wire encoders) can be connected.
Bidirectional digital inputs/outputs
4 digital inputs/outputs (DI/DO) are available on the SIMOTION D410.
The following application options are available when configuring the DI/DO as digital inputs:
●
The DI/DO9, 10 and 11 can be used as "fast inputs" for measuring inputs or for external
zero marks.
In the event of a signal edge on the respective input, the actual values of one or more
encoders are measured to the exact position to determine lengths and distances.
The inputs can be arranged in any way; the special application is activated in the SIMOTION
SCOUT Engineering System.
● All 4 DI/DO can be used as user-addressable inputs or as homing inputs.
The following application options are available when configuring the DI/DO as digital outputs:
● Use as onboard outputs
● Use as "fast cam outputs"
Note
Shielded cables are required when connecting probes or external zero marks to ensure
optimum noise immunity.
Additional references
For
information on commissioning the DI/DO as a user-addressable I/O, measuring inputs, or
cam outputs, refer to the
SIMOTION D410
Commissioning Manual.
For additional information on the commissioning and function of the technology objects TO
probes, TO cams, and TO cam tracks, refer to the
SIMOTION Output Cams and Measuring
Inputs
Function Manual.
4.3 DRIVE-CLiQ interface
Characteristics
The DRIVE-CLiQ interface has the following features:
● Automatic detection of components
● For the DRIVE-CLiQ interface, 24 V / 450 mA are available to connect encoders and
measuring systems.
Interfaces
4.3 DRIVE-CLiQ interface
SIMOTION D410
46 Manual, 04/2014
