SINUMERIK 802S base line Control System
SINUMERIK 802S base line
1-3
Start-Up
1.2 Technical data
Connected load
Table 1–1 Connected load
Parameter Min. Typ. Max. Unit
Supply voltage 20.4 24 28.8 V
Ripple 3.6 Vss
Current consumption from 24 V 1.5 A
Power dissipation of CNC 35 W
Start-up current 4 A
Weight
Table 1–2 Weight
Component Weight [g]
CNC 4500
Dimensions
Table 1–3 Component dimensions
Component Dimensions LxWxD [mm]
CNC 420 x 300 x 83
Environmental operating conditions
Table 1–4 Environmental operating conditions
Parameter
Temperature range
0...55 °C
Permissible relative humidity 5...95 % without condensation
Air pressure 700...1,060 hPa
The operating conditions comply with IEC 1131–2.
Installation in a housing (e.g. cubicle) is absolutely necessary for operation.
Transport and storage conditions
Table 1–5 Transport and storage conditions
Parameter
Temperature range
Transport: –40...70 °C
Storage: -20 ... 55 °C
Permissible relative air humidity 5...95 % without condensation
Air pressure 700...1,060 hPa
Transport height –1,000...3,000 m
Free fall in transport package
≤1,200 mm
Protective quality and degree of protection
Class of protection I to IEC 536.
No PE terminal required.
Foreign matter and water protection to IEC 529.
For CNC:IP 54 front IP 00 rear
