Technical Appendix
6-52
SINUMERIK 802S base line
Start-Up
6.3.6 User alarm
User alarm defined In SAMPLE
Alarm#
Interface
Address
Alarm Description SBR #
700000 V16000000.0 Startup! PLC MD needed, see description of PLC Lib
700001 V16000000.1
700002 V16000000.2 X+ traverse keys not defined, check MD14510[26]
700003 V16000000.3 X - traverse keys not defined, check MD14510[27]
700004 V16000000.4 Y+ traverse keys not defined, check MD14510[28]
700005 V16000000.5 Y - traverse keys not defined, check MD14510[29]
700006 V16000000.6 Z+ traverse keys not defined, check MD14510[30]
700007 V16000000.7 Z - traverse keys not defined, check MD14510[31]
700008 V16000001.0 Turret # wrongly defined, MD14510[20] = 4/ 6
700009 V16000001.1 Turret clamping time undefined, check MD14510[21]
700010 V16000001.2 Turret monitoring time undefined, check MD14510[22]
700011 V16000001.3 Spindle brake time out range, check MD14510[23]
700012 V16000001.4 Lubricating interval out range, check MD14510[24]
700013 V16000001.5 Lubricating duration out range, check MD14510[25]
31
700014 V16000001.6 Inputs undefined, check MD14512[0]&MD14512[1]
700015 V16000001.7 Outputs undefined, check MD14512[4]&MD14512[5]
Standard alarm defined In SAMPLE
Alarm #
Interface
Address
Alarm Description SBR #
700016 V16000002.0 DRIVES NOT READY, TOUCH K1 ON MCP
700017 V16000002.1 I
2
/T ALARM FOR INFEED MODULE
33
700018 V16000002.2
700019 V16000002.3
700020 V16000002.4
700021 V16000002.5 SPINDLE START IMPOSSIBLE WHILE UNCLAMPED 35
700022 V16000002.6 UNCLAMPING IMPOSSIBLE WHILE SPINDLE RUN 49
700023 V16000002.7 PROGRAMMED TOOL #. > MAX. TURRET ON
TURRET#
700024 V16000003.0 TOOL NOT FOUND, MONITORING TIME UP
700025 V16000003.1 NO POSITION SIGNALS FROM TURRET
46
700026 V16000003.2 MOTOR BRAKE RELEASED FOR DRIVE
OPTIMIZATION
700027 V16000003.3 APPROACH REF. POINT AGAIN AFTER ROT.
MONITORING
40
700028 V16000003.4
700029 V16000003.5
700030 V16000003.6
700031 V16000003.7
