Technical Appendix
SINUMERIK 802S base line
6-53
Start-Up
6.3.7 Start-Up of SAMPLE program
General
When first power on of the system, some important PLC machine datas must
be set.
Precedure
By first power on there will be one alarm – Alarm 700000 with text:
MA RESET AUTO
529
Number Del cri
C95HP.MPF
Alarm
Service
display
Start -
up
Machine
data
700000
Startup! PLC machine data needed, see description
of PLC Lib
700000
Fig. 6-2 Alarm screen form
Set following PLC machine data :
1. Define machine type: MD14510[16]=0: Lathe
MD14510[16]=1:Milling
2. Define Input and output: MD14512[0] ~ [4]: DI16 input enable and logic
MD14512[4] ~ [7]: DO16 output enable and logic
3. Define tranverse keys:
MD14510[26]: X + MD14510[27]: X –
MD14510[30]: Z + MD14510[31]: Z –
MD14510[28]: Y + (when MD14510[16]=1)
MD14510[29]: Y - (when MD14510[16]=1)
4. Shield E-stop signal: MD14512[16] Bit 0=1 E-stop disabled
5. Define application functions:
MD14512[11] Bit 7=1 Tool holder active for Turning
Bit 6=1 Spindle gear change active for Milling
Bit 3=1 Spindle control active
Bit 2=1 Unclamping control
Bit 1=1 Auto lubrication active
Bit 0=1 Cooling active
6. Define system parameter: MD14512 [16] / [17] / [18]
After setting, the parameter will be active when the next power on of the
system.
