Siemens SINUMERIK 802S Technical Manual

SINUMERIK 802S base line 1-1
Start-Up
SINUMERIK 802S base line
1
Control System
1.1 Components of the SINUMERIK 802S base line
What is SINUMERIK 802S base line?
The SINUMERIK 802S base line is a microprocessor-controlled numerical
control system for economic machine tools with stepper motor drives.
Hardware components
The SINUMERIK 802S base line is a compact CNC unit. It consists of the
following areas (see figure 1-1):
NDQ!Bsfb
OD!Lfzt
MDE
Fyuf sobm!tq joemf!esjwf
Tufq!Esjwft
T ufq!n pupst
Fig. 1-1 Components of SINUMERIK 802S base line (turning variant)
LCD
NC Keys
MCP Area
External spindle drive
Step motors
Step Drives
