SINUMERIK 802S base line
3-1
Start-Up
Installing the STEPDRIVE
3
General
The SINUMERIK802S base line can be configured with STEPDRIVE C/C+ or
FM STEPDRIVE. For the detailed description of FM STEPDRIVE, please refer
to the document on DOConCD (ordering number: 6FC5298-0CD00-0BG0).
3.1 Installing and dismantling the STEPDRIVE C/C+ drive modules
Warning
Before installing the STEPDRIVE C/C+ drive modules, first always make sure
that the equipment is disconnected from the mains.
Installation
To install the drive modules, proceed as follows (see Fig. 3–1):
1. Screw in the upper fastening screws M5 with washer and lock washer.
2. Hang the module into the clips of the upper fastening bracket.
3. Screw in the lower fastening screws and tighten all screws.
Notice
The modules should be installed such that a clearance of at least 10 cm is left
above, below and between the modules (dimension “a”).
The drive modules, however, can be mounted directly side by side (a> 10 mm)
provided they are ventilated with an air stream greater than / equal to 1 m/s.
Do not install devices which are strongly heated during operation beneath the
drive modules!
Dismantling
The drive modules are dismantled in the reverse order.
Warning
When removing the drive modules, always first make sure that the system is
disconnected from the mains!
!
