Siemens SINUMERIK 802S User Manual

Technical Appendix
6.1 List of machine and setting data
6-111
SINUMERIK 802S
6FC5 597–2AA00–0BP2 (01.02)
10074
PLC_IPO_TIME_RATIO
- PLC task factor for main run POWER ON
2 1 50 DWORD 2/7
10240
SCALING_SYSTEM_IS_METRIC
- Basic system metric POWER ON
_always 1 *** *** BOOLEAN 2/7
11100
AUXFU_MAXNUM_GROUP_ASSIGN
- Number of auxiliary functions distr. amongst aux. fct. groups POWER ON
_always 1 1 50 BYTE 2/7
11200
INIT_MD
HEX Standard machine data loaded on next Power On POWER ON
_always 0x0F - - BYTE 2/7
11210
UPLOAD_MD_CHANGE_ONLY
HEX Saving only of modified MD (value=0: complete= no difference) RESTART
– 0x0F – – BYTE 2/7
11310
HANDWH_REVERSE
- Threshold for direction change handwheel POWER ON
_always 2 0.0 plus BYTE 2/7
11320
HANDWH_IMP_PER_LATCH
- Handwheel pulses per detent position (handwheel number): 0...1 POWER ON
_always 1., 1. - - DOUBLE 2/7
14510
USER_DATA_INT [n]
kB User data (INT) 0 ... 31 POWER ON
_always - 0 - DWORD 2/7
14512
USER_DATA_HEX [n]
kB User data (Hex) 0 ... 31 POWER ON
- 0 0 0xFF BYTE 2/7
14514
USER_DATA_FLOAT [n]
- User data (Float) 0 ... 7 POWER ON
- 0.0 ... ... DOUBLE 2/7
14516
USER_DATA_PLC_ALARM [n]
- User data (Hex) Alarm bit 0 ... 31 POWER ON
- 0 0 0xFF BYTE 2/7
6.1.3 Channel-Specific Machine Data
Number MD Name
Unit Name, Miscellaneous Activated
HW / function Standard value Minimum value Maximum value D type User
class
20210
CUTCOM_CORNER_LIMIT
Degrees Maximum angle for compensation blocks with TRC POWER ON
_always 100 0.0 150. DOUBLE 2/7
20700
REFP_NC_START_LOCK
- NC-Start disable without reference point RESET
_always 1 0 1 BOOLEAN 2/7
