7.5 Additional machine data
7-161
SINUMERIK 802S
6FC5 597–2AA00–0BP2 (01.02)
In the Siemens standard user interface:
S Press the key to call the main selection screenform.
S Press the “Diagnosis” function key.
S Press the key to extend the function key bar.
S Press the “Language changeover” function key to switch to the alternative language.
7.5 Additional machine data
Limitations:
MD 14514 [0] $MN_USER_DATA_FLOAT [0] Max. input value for “Cut meters”
Lubrication:
MD 14510 [1] $MN_USER_DATA_INT [1] Lubrication time (x 100ms)
MD 14510 [2] $MN_USER_DATA_INT [2] Lubrication pause (x 100ms)
Spindle shutdown in “Chuck key position”:
MD 14510 [0] $MN_USER_DATA_INT [0] Time monitoring Spindle positioning (x 100ms)
MD 14514 [1] $MN_USER_DATA_FLOAT [1] Starting speed Spindle positioning
MD 14514 [2] $MN_USER_DATA_FLOAT [2] Tolerance window Spindle positioning
MD 35160 [4] $MA_SPIND_EXTERN_VELO_LIMIT
[2]
Spindle speed limitation from PLC Spindle positioning
7.6 Input limitations with regard to the user interface
Spindle: 0 < speed < MD 35100 [4] $MA_SPIND_VELO_LIMIT [4]
0 < cut meters < MD 14514 [0] $MN_USER_DATA_FLOAT [4]
