Siemens SINUMERIK 802S User Manual

Manual Machine
7.9 Default assignment of special data for the “Manual machine”
7-165
SINUMERIK 802S
6FC5 597–2AA00–0BP2 (01.02)
3rd module:
O 4.0 X2005 Pin 2 DO 0
O 4.1 PLC cycle time X2005 Pin 3 DO 1
O 4.2 X2005 Pin 4 DO 2
O 4.3 X2005 Pin 5 DO 3
O 4.4 X2005 Pin 6 DO 4
O 4.5 X2005 Pin 7 DO 5
O 4.6 X2005 Pin 8 DO 6
O 4.7 X2005 Pin 9 DO 7
O 5.0 X2006 Pin 2 DO 8
O 5.1 X2006 Pin 3 DO 9
O 5.2 X2006 Pin 4 DO 10
O 5.3 X2006 Pin 5 DO 11
O 5.4 X2006 Pin 6 DO 12
O 5.5 X2006 Pin 7 DO 13
O 5.6 X2006 Pin 8 DO 14
O 5.7 X2006 Pin 9 DO 15
7.9 Default assignment of special data for the “Manual machine”
Machine data:
MD 12010 $MN_OVR_FACTOR_AX_SPEED[1] 0.1
MD 12010 $MN_OVR_FACTOR_AX_SPEED[2] 0.2
MD 12010 $MN_OVR_FACTOR_AX_SPEED[3] 0.3
MD 12010 $MN_OVR_FACTOR_AX_SPEED[4] 0.4
MD 12010 $MN_OVR_FACTOR_AX_SPEED[5] 0.5
MD 12010 $MN_OVR_FACTOR_AX_SPEED[6] 0.6
MD 12010 $MN_OVR_FACTOR_AX_SPEED[7] 0.7
MD 12010 $MN_OVR_FACTOR_AX_SPEED[8] 0.8
MD 12010 $MN_OVR_FACTOR_AX_SPEED[9] 0.9
MD 12010 $MN_OVR_FACTOR_AX_SPEED[10] 0.95
MD 12010 $MN_OVR_FACTOR_AX_SPEED[11] 1
MD 12010 $MN_OVR_FACTOR_AX_SPEED[12] 1.05
MD 12010 $MN_OVR_FACTOR_AX_SPEED[13] 1.1
MD 12010 $MN_OVR_FACTOR_AX_SPEED[14] 1.2
MD 12010 $MN_OVR_FACTOR_AX_SPEED[15] 1.2
MD 12010 $MN_OVR_FACTOR_AX_SPEED[16] 1.2
MD 12010 $MN_OVR_FACTOR_AX_SPEED[17] 1.2
MD 12010 $MN_OVR_FACTOR_AX_SPEED[18] 1.2
