SINUMERIK 802S Control System
1.2 Technical data
1-14
SINUMERIK 802S
6FC5 597–2AA00–0BP2 (01.02)
Environmental operating conditions
Table 1-4 Environmental operating conditions
Parameter
Temperature range 0...55 °C
Permissible relative humidity 5...95 % without condensation
Air pressure 700...1,060 hPa
The operating conditions comply with IEC 1131-2.
Installation in a housing (e.g. cubicle) is absolutely necessary for operation.
Transport and storage conditions
Table 1-5 Transport and storage conditions
Parameter
Temperature range Transport: -40...70 °C
Storage: –20 ... 55 °C
Permissible relative air humidity 5...95 % without condensation
Air pressure 700...1,060 hPa
Transport height -1,000...3,000 m
Free fall in transport package v 1,200 mm
Protective quality and degree of protection
Class of protection I to IEC 536.
No PE terminal required.
Foreign matter and water protection to IEC 529.
S for ENC and DI/O16: IP 20
S for OP020 and MCP: IP 54 front
IP 00 rear
