Siemens SINUMERIK 808D ADVANCED Parameter Manual

22020 AUXFU_ASSIGN_EXTENSION C04 H2, S1
- Auxiliary function extension DWORD PowerOn
-
- 64 0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0,, ...
-1 99 2/2 M
Description: See MD22010 $MC_AUXFU_ASSIGN_TYPE[n] (auxiliary function type)
Special cases:
With the spindle functions M3, M4, M5, M19, M70, M40, M41, M42, M43, M44, M45 and S,
the spindle number is output to the PLC in the auxiliary function extension.
22030 AUXFU_ASSIGN_VALUE C04 H2, S1
- Auxiliary function value DWORD PowerOn
-
- 64 8, 9, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0,
- - 2/2 M
Description: See MD22010 $MC_AUXFU_ASSIGN_TYPE[n] (auxiliary function type)
22035 AUXFU_ASSIGN_SPEC C04 H2
- Output specification DWORD PowerOn
-
- 64 0x21, 0x21, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0,
0 0x7FFFFFFF 2/2 M
Description: Specification of the output behavior of the user-defined auxiliary functions.
Bit 0 = 1 Acknowledgment "normal" after an OB1 cycle
Bit 1 = 1 Acknowledgment "quick" with OB40
Bit 2 = 1 No predefined auxiliary function
Bit 3 = 1 No output to the PLC
Bit 4 = 1 Spindle reaction after acknowledgment by the PLC
Bit 5 = 1 Output before the motion
Bit 6 = 1 Output during the motion
Bit 7 = 1 Output at block end
Bit 8 = 1 No output after block search types 1, 2, 4
Bit 9 = 1 Collection during block search type 5 (SERUPRO)
Bit 10 = 1 No output during block search type 5 (SERUPRO)
Bit 11 = 1 Cross-channel auxiliary function (SERUPRO)
Bit 12 = 1 Output via synchronized action
Bit 13 = 1 Implicit auxiliary function
Bit 14 = 1 Active M01
Bit 15 = 1 No output during running-in test
Bit 16 = 1 Nibbling off
Bit 17 = 1 Nibbling on
Bit 18 = 1 Nibbling
Machine data
3.3 Channel-specific machine data
Parameter Manual
Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1 167
