Siemens SINUMERIK 808D ADVANCED Parameter Manual

0 Activation of alarm no.
700007 700006 700005 700004 700003 700002 700001 700000
1 Activation of alarm no.
700015 700014 700013 700012 700011 700010 700009 700008
2 Activation of alarm no.
700023 700022 700021 700020 700019 700018 700017 700016
3 Activation of alarm no.
700031 700030 700029 700028 700027 700026 700025 700024
4 Activation of alarm no.
700039 700038 700037 700036 700035 700034 700033 700032
5 Activation of alarm no.
700047 700046 700045 700044 700043 700042 700041 700040
... ...
15 Activation of alarm no.
700127 700126 700125 700124 700123 700122 700121 700120
6.4.2 Variables for user alarms
DB1600 Variables for user alarms [r32/w32]
PLC -> HMI interface
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
DBD1000 Variable for alarm 700000
DBD1004 Variable for alarm 700001
DBD1008 Variable for alarm 700002
… …
DBD1500 Variable for alarm 700125
DBD1504 Variable for alarm 700126
DBD1508 Variable for alarm 700127
6.4.3 Active alarm response
DB1600 Active alarm response [r]
PLC -> HMI interface
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
2000 Acknowledge
POWER ON
Acknowledge
with
DB1600DBX3
000.0
PLC STOP EMERGENCY
STOP
Feedrate disa‐
ble all axes
Read-in
disable
NC start
disable
2001
PLC user interface
6.4 User Alarms
Parameter Manual
Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1 457
