Signal state 1(status-
controlled)
If the new gearbox stage is engaged, then the PLC user sets the IS "Actual
gear stage A" to "...C" and the IS "Gear is changed over". This signals to the
NCK that the correct gear stage has been successfully engaged. The gear
change is considered to have been completed (spindle oscillation mode is
deselected), the spindle accelerates in the new gear stage to the last pro‐
grammed spindle speed and the next block in the parts program can be exe‐
cuted.
The actual gear stage is specified coded (ABC values).
There is one
parameter set for each of the 5 gear stages, which is parameter‐
ized as follows:
Parameter
set No.
Code
CBA
Data of the data set Content
0 - Data for axis mode Kv factor
Monitoring
1 000 Data for the 1st gear stage M40 speed
001 Min / max speed
Acceleration
2 010 Data for the 2nd gear stage etc.
3 011 Data for the 3rd gear stage
4 100 Data for the 4th gear stage
5 101 Data for the 5th gear stage
110
111
Special cases, er‐
rors, ...
If the PLC user signals back to the NCK with a different actual gear stage than
issued
by the
NCK as the setpoint gear stage, the gear change is still consid‐
ered to have been successfully completed and the actual gear stage A to C is
activated.
corresponding to ... IS "Setpoint gear stage A" to "...C" (DB390x DBX2000.0 to .2)
IS "Change gear stage" (DB390x DBX2000.3)
IS "Gear stage is changed over" (DB380x DBX2000.3)
IS "Oscillation speed" (DB380x DBX2002.5)
Parameter sets (MDs) for gear stages
Note for the reader Function Manual Basic Functions S1
DB380x
DBX2000.3
Gear is changed over
Signal(s) to axis / spindle (PLC → NCK)
Edge evaluation: Yes Signal(s) updated: Cyclic
Signal state 1 or edge
change 0 → 1
If the new gearbox stage is engaged, then the PLC user program sets the
IS
"Actual gear
stage A to C" and the IS "Gear stage is changed over". This
signals the NCK that the correct gear stage has been successfully engaged.
The gear stage change is complete (spindle oscillation mode is deselected),
the spindle accelerates in the new gear stage to the last programmed spindle
speed and the next block in the parts program can be executed. The NCK
resets the IS "Change gear stage" and then the PLC user program resets
the IS "Gear stage is changed over".
Signal state 0 or edge
change 1 → 0
No effect
Signal irrelevant for ... spindle modes other than the oscillation mode
Detailed descriptions of interface signals
5.8 Axis / spindle-specific signals
Parameter Manual
420 Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1
