Siemens SINUMERIK 808D ADVANCED Parameter Manual

808d-mte40 3 1.0, 1.0, 1.0, 1.0, 1.0,
1.0, 1.0, 1.0, 1.0, 1.0,
1.0, 1.0, 1.0,...
0.0 - 7/7 U
808d-mte60 3 1.0, 1.0, 1.0, 1.0, 1.0,
1.0, 1.0, 1.0, 1.0, 1.0,
1.0, 1.0, 1.0,...
0.0 - 7/7 U
Description: The setting data specifies a typical tool radius. It is evaluated for the COMPSURF
compressor
only.
A
smaller value results in greater precision but also slower program
execution.
42473 ACTNUM_SURF_GROUPS EXP, C09 -
- Currently desired COMPSURF function dimensioning in respect
of axis groups.
DWORD Immediately
-
808d-me42 - 1, 1, 1, 1, 1, 1, 1, 1... 1 3 0/0 S
808d-me62 - 1, 1, 1, 1, 1, 1, 1, 1... 1 3 2/2 M
808d-te42 - 1, 1, 1, 1, 1, 1, 1, 1... 1 3 0/0 S
808d-te62 - 1, 1, 1, 1, 1, 1, 1, 1... 1 3 0/0 S
808d-mte40 - 1, 1, 1, 1, 1, 1, 1, 1... 1 3 7/7 U
808d-mte60 - 1, 1, 1, 1, 1, 1, 1, 1... 1 3 7/7 U
Description: The setting data dimensions the COMPSURF function in respect of axis groups for
following machining. Values greater than $MC_MM_MAXNUM_SURF_GROUPS are limited without
an alarm.
Related to:
MD28072 $MC_MM_MAXNUM_SURF_GROUPS
42474 SURF_SMOOTHING_LEVEL EXP, C09 -
- Optimization level for the COMPSURF function.
[0] Smoothing stage for geometry axes
[1] Smoothing stage for the orientation axes
[2] Smoothing stage for other axes
DWORD Immediately
-
808d-me42 3 1, 1, 1, 1, 1, 1, 1, 1, 1,
1, 1, 1, 1, 1, 1, 1, 1, 1,
1, 1, 1, 1...
1 10 0/0 S
808d-me62 3 1, 1, 1, 1, 1, 1, 1, 1, 1,
1, 1, 1, 1, 1, 1, 1, 1, 1,
1, 1, 1, 1...
1 10 2/2 M
808d-te42 3 1, 1, 1, 1, 1, 1, 1, 1, 1,
1, 1, 1, 1, 1, 1, 1, 1, 1,
1, 1, 1, 1...
1 10 0/0 S
808d-te62 3 1, 1, 1, 1, 1, 1, 1, 1, 1,
1, 1, 1, 1, 1, 1, 1, 1, 1,
1, 1, 1, 1...
1 10 0/0 S
808d-mte40 3 1, 1, 1, 1, 1, 1, 1, 1, 1,
1, 1, 1, 1, 1, 1, 1, 1, 1,
1, 1, 1, 1...
1 10 7/7 U
808d-mte60 3 1, 1, 1, 1, 1, 1, 1, 1, 1,
1, 1, 1, 1, 1, 1, 1, 1, 1,
1, 1, 1, 1...
1 10 7/7 U
Description: The setting data defines the smoothing stage of the COMPSURF function. A higher value
means smoother surfaces but also lower accuracy.
Related to:
NC setting data
Parameter Manual
Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1 317
