Application Control of automatic tool selection.
corresponding to ... IS "S function for the spindle (REAL), axis-specific" (DB370x DBD4)
Note for the reader Function Manual Basic Functions H2
DB2500
DBD5000
D function 1
Signal(s) from channel (PLC)
Edge evaluation: No Signal(s) updated: job-control‐
led by NCK
Signal state 1 The D function programmed in an NC block is made available here as soon
as the D change signal is available.
Value range of the D function: 0-9; integer number
The D function remains valid until it is overwritten by a new D function.
Signal state 0
● After the PLC has ramped-up.
●
All auxiliary functions are deleted before a new function is entered.
Application
corresponding to ... D0 is reserved for deselecting the actual tool offset.
Note for the reader Function Manual Basic Functions H2
DB2500
DBD6000
DBD6008
DBD6016
DBW6004
DBW6012
DBW6020
H function 1
H function 2
H function 3
Extended address of H function 1
Extended address of H function 2
Extended address of H function 3
Signal(s) from channel (PLC)
Edge evaluation: No Signal(s) updated: job-control‐
led by NCK
Signal state 1 Up to 3 H functions programmed in an NC block are simultaneously made
available here as soon as the H change signals are available.
Value range of the H functions: Floating point (REAL format/4 bytes)
Value range of the extended address: 0 to 99; integer number
The H functions remain valid until they are overwritten by new H functions.
Signal state 0
● After the PLC has ramped-up.
●
All auxiliary functions are deleted before a new function is entered.
Application Switching functions on the machine.
Note for the reader Function Manual Basic Functions H2
Detailed descriptions of interface signals
5.4 Auxiliary function transfer from NC channel
Parameter Manual
Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1 367
