Load Weighing Device
September 29,2021 ©2021 Smartrise Engineering, Inc. All Rights Reserved Page 11
Learning Load Values
The following procedure describes how to perform an empty car learn.
1. Press the left button until the LOAD WEIGHER SETUP menu displays.
2. From the LOAD WEIGHING SETUP menu, scroll and select Trigger Recalibrate.
Figure 26: LOAD WEIGHER SETUP Menu – Trigger Recalibrate
3. From the TRIGGER RECALIBRATE menu, scroll and select On.
Figure 27: TRIGGER RECALIBRATE Menu – On
4. Scroll right and press Save.
5. The car is captured and moves from floor to floor to learn the empty load weight
starting at the bottom floor. When the operation is complete, the On status will still be
displayed but since the actual setting of this flag has changed back to Off, the Save
notation will appear on the screen.
Figure 28: TRIGGER RECALIBRATE Menu – Learned
6. Scroll back and select Trigger Recalibrate. The TRIGGER RECALIBRATE status displays Off.
Figure 29: TRIGGER RECALIBRATE Menu – Off
The following procedure describes how to perform a full load learn.
1. Press the left button until the LOAD WEIGHER SETUP menu displays.
