Smartrise C4 Manual

Load Weighing Device
Page 18 ©2021 Smartrise Engineering, Inc. All Rights Reserved September 29,2021
22. From the SETUP menu, scroll and select Brake Setup.
Figure 52: SETUP Menu – Brake Setup
23. From the BRAKE SETUP menu, scroll and select Primary Setup.
Figure 53: BRAKE SETUP Menu – Primary Setup
24. From the BRAKE SETUP menu, select Ramp Time – Auto.
Figure 54: BRAKE SETUP Menu – Ramp Time – Auto
25. From the BRAKE RAMP TIME (AUTO) menu, set the ramp time speed to 100 msec.
Figure 55: BRAKE RAMP TIME (AUTO) Menu
26. Scroll right and press Save.
27. Press the left button until the BRAKE SETUP menu displays.
28. From the BRAKE SETUP menu, scroll and select Ramp Time – Insp.
Figure 56: BRAKE SETUP Menu – Ramp Time – Insp
