Sony CCP-8000 System Setup Manual

2-6
MVS-8000 System
SYSTEM SETUP
2-4. CCP-8000 Installation
2-4-1. Installation Space
When the main panel or the AUX panel are embedded into a control console or the like, make holes as
shown below into the control console with the following dimensions.
Be sure to have an open space behind the cables of the connectors on the main panel shown as open space
at “A” in the illustrations.
X
X
X
57.2
67
134
5.55.5
88.988.988.988.911.511.5
132.1
264.3
396.467.5
88.988.988.9
132.1
264.3
400
67.5
532
5.5
5.5
5.5
11
3040
20
100
11
11 11
TYPE
32XPT SEPARATED
24XPT SEPARATED
16XPT SEPARATED
32XPT INTEGRATED
24XPT INTEGRATED
16XPT INTEGRATED
X
1205
1053
901
1425
1273
1121
TYPE
32XPT SEPARATED
24XPT SEPARATED
16XPT SEPARATED
32XPT INTEGRATED
24XPT INTEGRATED
16XPT INTEGRATED
X
1205
1053
901
1425
1273
1121
32XPT SEPARATED
24XPT SEPARATED
16XPT SEPARATED
32XPT INTEGRATED
24XPT INTEGRATED
16XPT INTEGRATED
SHORT SIZE
765
613
461
765
613
461
FULL SIZE
1205
1053
901
1425
1273
1121
TYPE
X
4-M5
<AUX panel>
<Main panel x 4 lines
(4ME/3ME with built in AUX bus as a signle unit)>
<Main panel x 3 lines
(3ME with AUX bus separate type/2ME)>
16-ø5 hole with depth of 3 or more
Open space at “A”
Open space at “A”
12-ø5 hole with depth of 3 or more
8-M4
6-M4
20
5.5
30
20
100
Open space at “A”
Top
Bottom
40
Open space at “A”
20
Top
Bottom
Unit : mm
2-4. CCP-8000 Installation
