3-2
MVS-8000 System
SYSTEM SETUP
3-3. IP Address
The MVS-8000 system uses IP address 10.x.x.x.
Each device of MVS-8000 system has independent NETWORK terminal for each LAN.
The IP address for all NETWORK terminals has same rules as below.
The IP address is identified by four byte of the form below.
10.AA.BB.CC
ex. 10.1.2.1
10. AA. BB. CC.
Fixed GROUP ID + LAN ID Unit cord (Fixed) Unit ID
GROUP ID is defined as DIP It uses to identify unit category. Unit ID is defined as DIP SW of
SW of GROUP ID 1 to 63. UNIT ID 1 to 254.
LAN IDs are as follows ;
Control LAN : 0
Peripheral LAN : 64
Data LAN : 128
Used bit for LAN Group ; Unit category are as follows ; Used bit ;
Control LAN : 1 to 63 PANEL : 1 1 to 254
*1
Peripheral LAN : 65 to 127 SWITCHER : 2
Data LAN : 129 to 191 DME : 3
PFV-SP : 4
DCU : 5
ROUTER : 6
*1 : the default setting is “1”.
Host name
When IP address is defined, it is also named host name automatically.
The host name is identified by ten digits (characters and numbers) of the format below.
Format :
Unit name (3 characters) + Group ID (3 digits) + LAN code (1 character) + Unit ID (3 digits)
Example :
IP address : 10.1.1.1 Host name : PNL001C001
Unit category Unit name
PANEL PNL
SWITCHER SWR
DME DME
DCU DCU
Group ID + LAN Code
Control LAN 001C to 063C
Peripheral LAN 001P to 063P
Data LAN 001D to 063D
