1-1
MVS-8000 System
SYSTEM SETUP
Section 1
System Overview
1-1. Introduction
The MVS-8000 system has integrated a wide variety of new features including SDTV and HDTV televi-
sion signal capability, advanced networking and layout-free control panels.
The MVS-8000 system includes SD/HD simulcast, multiple frame rates and resolutions, multi-channel
casting and even broadcast equipment sharing, to name just a few.
The MVS-8000 system is completely ready for smooth integration into current systems, offering the
added quality, reliability and features, needed for the live/post production environment.
The MVS series can be flexibly expanded as a user’s needs grow simply installing the appropriate options
to the basic system.
1-2. Features
Flexible configurations
Item Expandable number Expansion basis
M/E configuration 2 M/E Per M/E
3 M/E
4 M/E
Inputs SD: up to 80 inputs Per 17 inputs
HD: up to 68 inputs
Outputs 56 assignable outputs Per 8 outputs
(including 8 monitor outputs)
DME Channel 1 to 8 CH Per 1 CH
(4 CH in one chassis)
SD/HD capability
High definition Standard definition
1080i/60/59.94/50 480i/59.94
1080PsF/30/29.97/25/24/23.976 576i/50
720p/59.94 (future)
To Next Page
