MVS-8000 System
SYSTEM SETUP
2-7. MVS-8000 System Control Cabling
2-7-2. LAN Requirements
The MVS-8000 system requires an Ethernet Local Area Network (LAN) for System Control LAN and
Data LAN.
Switcher Processor (MVS-8000), DME Processor (MKS-8800), and System Control Unit (MKS-8010)
are all connected via an Ethernet switch of appropriate specification.
Data LAN requires separate Ethernet switch from the one for Control LAN to avoid delay of the process-
ing.
m
. Ethernet Hubs are not acceptable for the MVS-8000 system Ethernet connection.
Use of hub instead of a switch may cause sluggish responses to panel button.
Connect each LAN (Control/Data) nodes to the different switch to avoid sluggish.
. Ethernet switches are not supplied with MVS-8000 system.
Ethernet specification
Refer to Table below for a list of required Ethernet Specifications for MVS-8000 system.
Ethernet specification
Cable Type 100 BASE-TX compatible.
Connectors RJ-45 male connector at each end of cable
Length 100 m maximum
Switch Capacity of backbone Higher than 1.5 Gbps
Throughput Higher than 120 Kbps (a port) packet size 64 Byte
Total throughput : higher than 3 Mbps
Delay time of packet Less than 50u sec
Speed Dual : 100 Mbps
Ports RJ-45 auto negotiating 100 Mbps
Number of ports required is dependent upon system configuration
VALN Compatible
Switching mode Store-and-Forward
Management SNMP, RMON
