Sony DFS-900M User Manual

145
Customizing DME Effects
Chapter 5 Adjusting Wipes and Keys
(xxx: “M/E DME” appears if you are setting up a
transition, and “Keyer” appears if you are setting up a key.)
xxx Splits 1 (1)
xxx Splits 2 (2)
Mirror sub menu parameters
Adjust the following parameters to adjust the Mirror
effect.
Mirror effect example
The Mirror sub menu has two pages. To switch between
pages, press the h and H buttons in the numeric
keypad.
(xxx: “M/E DME” appears if you are setting up a
transition, and “Keyer” appears if you are setting up a key.)
xxx Mirror 1 (1)
xxx Mirror 2 (2)
Defocus sub menu parameters
Adjust the following parameter to specify the level
(amount of blurring) of the Defocus effect.
Operation Knob Parameter Settings
Select the type
of division.
F1 Typ (Type) 2Way-H: Divided
into two parts,
left and right
2Way-V: Divided
into two parts,
top and bottom
4Way: Divided into
four parts
Multi: Divided into
multiple parts
Specify the
rotation angle of
the divisions
(when Multi is
selected).
F2 Rot
(Rotation)
–8.000 to 8.000
Adjust the
distance
between the
parts when
dividing into a
spiral.
F3 Spl (Spiral) –8.000 to 8.000
Adjust the
displacement
between parts
when parts are
staggered.
F4 Stg
(Stagger)
–8.000 to 8.000
Operation Knob Parameter Settings
Specify the
number of
divisions (when
Multi is
selected).
F1 Num (Num_
Segment)
3 to 31
Specify the X
coordinate of
the center point
of the division
(when Multi is
selected).
F2 PX (Position
X)
–8.000 to 8.000
Specify the Y
coordinate of
the center point
of the division
(when Multi is
selected).
F3 PY (Position
Y)
–8.000 to 8.000
Specify the
amount of
movement of
the divided
area.
F4 Amt
(Amount)
–2.000 to 2.000
Operation Knob Parameter Settings
Specify the type
of division.
F1 Typ (Type) 2Way0 (2 way, 0)
2Way1 (2 way, 1)
2Way2 (2 way, 2)
2Way3 (2 way, 3)
4Way0 (4 way, 0)
4Way1 (4 way, 1)
4Way2 (4 way, 2)
4Way3 (4 way, 3)
Multi (multiple
divisions)
Specify the
rotation angle of
the mirror (when
Multi is
selected).
F2 Rot
(Rotation)
–8.000 to 8.000
Operation Knob Parameter Settings
Specify the
number of
mirrors (when
Multi is
selected).
F1 Num (Num_
Segment)
1 to 31
Specify the X
coordinate of
the center point
of the mirror.
F2 PX (Position
X)
–8.000 to 8.000
Specify the Y
coordinate of
the center point
of the mirror.
F3 PY (Position
Y)
–8.000 to 8.000
