Installing Optional Expansion Boards
Chapter 3 Preparations
Installing Optional Expansion Boards
This section explains how to install I/O expansion boards, function expansion
boards, and the optional power supply unit.
The following expansion options are available. For more information about the
various options, see page 31.
• Always power off all devices before starting the operation for installing or
removing expansion options.
• The processor unit will still be hot immediately after it is powered off.
Always wait at least 30 minutes before starting the operation for
installing or removing expansion options.
• Always install expansion options in the designated locations.
• Always install expansion options using the screws supplied with the
expansion options. Use of other screws may damage the expansion options or
processor unit.
• Be careful to avoid injury when installing and removing expansion options.
• You can use the Status sub menu of the Setup menu to check whether
expansion options are installed. For details, see page 170.
Installing I/O Expansion Boards
About installation locations and channel numbers
Pull out the expansion board installation trays from the I/O expansion board
slots (lower and upper) on the rear panel of the processor unit, use the screws
supplied with the boards to secure them to trays, and then return the trays to the
slots. Facing the processor unit, install the input expansion boards at the far left
and center positions, and install the output expansion boards at the far right
position.
Type and function of expansion options Model number
Input expansion
boards
4 SDI Input Board BKDF-910
2 SD Video Input Board BKDF-911
2 DVI Input Board BKDF-912
Output expansion
boards
4 SDI Output Board BKDF-960
2 SD Video Output
Board
BKDF-961
2 DVI Output Board BKDF-962
Function expansion
boards
2CH DME Board BKDF-940
Multi Viewer Board BKDF-950
Power supply unit BKDF-990
Notes
