Sony DFS-900M User Manual

26
BKDF-902 1.5M/E Control Panel
Chapter 2 Names and Functions of Parts
a DME setting buttons
See descriptions of “DME setting buttons” (page 18) for
the BKDF-901.
b USER button
Displays the menu used for management of user specified
wipe patterns and DME wipe patterns.
c Setup buttons
See descriptions of “Setup buttons” (page 18) for the
BKDF-901.
d STILL button
Displays the menu for still image storage operations, such
as download, capture, and export.
0 Joystick Block
See descriptions for the BKDF-901 in “6 Joystick Block”
(page 16).
qa Numeric Keypad
See descriptions for the BKDF-901 in “7 Numeric
Keypad” (page 17).
qs Display Panel/Menu Control
Block
See descriptions for the BKDF-901 in “9 Display Panel/
Menu Control Block” (page 19).
BKDF-902 Rear Panel
Two -AC IN connectors (A and B) and two POWER
switches (A and B) are provided with the BKDF-902.
2 USER button
3 Setup buttons
4 STILL button
1 DME setting buttons
