75
Basic Switcher Settings
Chapter 3 Preparations
1
Insert a USB flash drive into the USB MEMORY connector.
2
When using the BKDF-901: If the SHIFT button of the DME/SETUP
block is not lit, press it to light it.
When using the BKDF-902: Skip to step 3.
3
Press the INPUT button.
A settings sub menu of the Input (input signal settings) sub menu appears in
the display panel.
4
Press the h or H button in the numeric keypad until the Signal Rename
sub menu appears.
“Signal Rename” appears in the sub menu title display area. If it is already
displayed there, you can skip this step.
5
Hold the F1 knob down for one second or longer.
A file containing a list of the signal names (dfs900.ini) is saved in the root
directory of the USB flash drive.
The file is a text file, with content in the following format.
BKDF-901
BKDF-902
To Next Page
