Adjusting Settings
Video Settings
You can adjust settings for video.
Lets you convert the resolution of analog video input signals and output the converted signals.
x Direct
Lets you output analog video input signals
directly.
x Auto
x 480i/576i
x 480p/576p
x 720p
x 1080i
x 1080p
When an HDMI monitor is being connected with HDMI OUT ON
When an HDMI monitor is not connected with HDMI OUT OFF
Resolution (Converting video signals)
“Resolution”
menu setting
HDMI OUT
jacks
MONITOR
COMPONENT
VIDEO OUT jacks
MONITOR VIDEO
OUT jack
Direct, Auto HDMI IN jacks z ––
COMPONENT VIDEO IN
jacks
a
a)
z –
VIDEO IN jacks a
a)
– z
480i/576i, 480p/
576p, 720p, 1080i,
1080p
HDMI IN jacks z ––
COMPONENT VIDEO IN
jacks
a
b)
z –
VIDEO IN jacks a
b)
– z
“Resolution”
menu setting
HDMI OUT
jacks
MONITOR
COMPONENT
VIDEO OUT jacks
MONITOR VIDEO
OUT jack
Direct HDMI IN jacks – – –
COMPONENT VIDEO IN
jacks
– z –
VIDEO IN jacks – – z
Auto HDMI IN jacks – – –
COMPONENT VIDEO IN
jacks
– 480i/576i a
VIDEO IN jacks – 480i/576i z
Input from
Output from
Input from
Output from
continued
