Chapter 2 Menu
This section explains the setting lists displayed in the
menu.
How to read the setting lists
•For purposes of explanation, each setting list is
preceded by a menu number. These numbers are not
displayed on the screen.
For more information about the menu number, see “About
menu numbers” on page 16.
•The arrow mark (k) refers you to another setting list
that appears after you make the setting, or to an
operation that is carried out as a result of the setting.
When there is no arrow mark, the menu does not have
any sub-list.
[C1] INPUT CONFIGURATION menu (1/2)
Set input signal data for each channel.
CHxx: Current channel is indicated. To change the
channel, enter a channel number with the numeric
keypad. The settings below will be stored as
information about the signal to be connected to this
channel.
FORMAT... : Select the input signal type. k[C11]
SCAN CONVERSION: Select the frame rate of the
HD-SDI signal. k[C12]
LINK NO: Select the link number from among DUAL
LINK, SINGLE LINK 1 and SINGLE LINK 2.
SYNC MODE: Select the sync signal.
INT: Use an internal sync signal.
EXT: Use an external sync signal.
When a sync signal is input to the VD terminal,
the external separate sync mode (HD/VD) is
selected automatically.
SCREEN MODE: Select the scan size.
NORMAL: Overscan
UNDER: Underscan
SAFE AREA DISPLAY: Choose whether or not to
display the safe area (OFF or ON). This function
can be used for the PC format. When the H delay
and/or V delay function is used, the safe area
cannot be displayed.
MODE...: Select the display mode for safe area.
k[C13]
SAFE TITLE DISPLAY: Choose whether or not
to display the safe title area (OFF or ON). This
function can be used for the PC format.
Setting Lists in the INPUT CONFIGURATION Menu
MODE...: Set the position and size of the safe title
area (lower right corner: 0). First set the H
POSITION and V POSITION, and then
WIDTH and HEIGHT.
STD H POSITION: First horizontal position of
the title area
STD V POSITION: First vertical position of the
title area
STD WIDTH: Width of the title area
STD HEIGHT: Height of the title area
[C1] INPUT CONFIGURATION menu (2/2)
Set input signal data for each channel.
CHxx: Current channel is indicated. To change the
channel, enter a channel number with the numeric
keypad. The settings below will be stored as
information about the signal to be connected to this
channel.
CHANNEL NAME... : Give the channel a name.
k [C14]
CONTROL: Use if either PRESET or CH SET
values are used for the CONTRAST/BRIGHT
settings.
PRESET: Use values common to all channels.
CH SET: Use individual values for each channel.
COLOR TEMP...: Set the color temperature.
k [C15]
H PHASE: Set the horizontal picture position (–128 to
+127).
COPY FROM... : Select a method for copying data
from elsewhere. k[C16]
Note
For H PHASE data, if a value above or below the
allowable range is entered, the monitor will not
operate correctly.
[C11] FORMAT menu
Select the signal format.
HD SDI 4:2:2 YPBPR: HD serial digital component
4:2:2 signal
HD SDI 4:4:4 YPBPR: HD serial digital component
4:4:4 signal
HD SDI 4:4:4 GBR: HD serial digital 4:4:4 signal
ANALOG RGB: Analog RGB signal
(continued)
To Next Page
