4
Chapter 1 Overview
The BVM-F24E/F24U/F24A is 24-inch
1)
Trinitron
®2)
Color Video Monitor. This is suitable for television
stations or video production houses, where precise
image reproduction is required.
Features
Built-in HD-SDI decoder
This monitor is equipped with two pairs of input/
output connectors for HD-SDI signals and input
connectors for analog RGB signals.
Support of multiformat signals such as 1080/
24P, 24PsF* and 60P
This monitor supports multiformats
3)
such as 1080/24P
formats signal which are suitable for film production
and 1080/50P, 60P (conforming to SMPTE-274M)
formats for broadcasting in the near future and
standardized formats whose horizontal frequency is
between 54 kHz and 91.1 kHz.
*24PsF: 24 Progressive segmented frame
HD-SDI input frame rate converter
HD-SDI signals are scanned twice or three times
through a frame rate conversion process.
When viewing 24-frame material, the internal circuitry
eliminates picture flicker.
Input signal
Internal
Output signal
conversion
1080/24P, 25P ×2, ×3 1080/48P, 50P, 72P, 75P
1080/24PsF, ×2, ×3 1080/48P, 50P, 72P, 75P
25PsF
1080/30P, 30PsF ×2 1080/60P
* These signal formats show the active lines per frame.
* Also compatible with 1/1.001 for 24P, 24PsF, 30P and
30PsF.
Dual Link HD-SDI mode
1080/24P (4:4:4), 1080/60I (4:4:4) and 1080/60P
(4:2:2) signals can be received using the dual link HD-
SDI mode supported by the serial digital interface.
* RGB signals or YPbPr signals are selectable in the menu
for 4:4:4 modes.
Overview
Pseudo signal display for 1080/60I, 720/60P
signals, etc.
The pseudo signal display is used to display 1080/50I
or 60I, 720/60P, or 1080/24PsF, 25PsF or 30 PsF
format signals that this monitor does not adjust.
Accepts SXGA format signal
This monitor accepts RGB signals (only SXGA signals
in the table) from the computer. This is suitable for
computer graphics work where the precise image
reproduction is required.
Signal
Horizontal
Frame rate (Hz)
frequency (kHz)
1280 × 1024/75 80.0 75
(VESA STD)
1280 × 1024/85 91.1 85
(VESA STD)
High resolution picture tube
Flat HR Trinitron picture tube offering 16:9 aspect
ratio display and SMPTE-C (BVM-F24U) or EBU
(BVM-F24E/F24A) phosphors produce a clear, high
resolution image.
Aperture grille pitch: 0.25 mm to 0.28 mm
Resolution at the center of the picture:
1000 TV lines
Various safe area display functions
This monitor is equipped with the following safe area
display functions
- cross marker which shows picture center
- aspect area display function which displays frame
boundaries and supports the various film aspect ratios
- safe title display function for title area
- letter box/4:3 area marker (with settings selectable
from line, semitransparent mat and fullblack mat)
Original setting data can be memorized.
Separate control unit
Using a separate control unit reduces the space needed
for the equipment.
1) The CRT size of the monitor.
For effective picture size, see “Specifications” on page 57.
2) Trinitron
®
is a registered trademark of Sony Corporation.
3) For details on the signal format, see “HD-SDI Input and Display Available Signal Formats” on page 59 and “Analog RGB
Available Signal Formats” on page 60.
........................................................................................................................................................................................................
