36
Chapter 2 Menu
Setting Lists of the REMOTE Menu
This section explains the setting lists displayed in the
menu.
How to read the setting lists
•For purposes of explanation, each setting list is
preceded by a menu number. These numbers are not
displayed on the screen.
For more information about the menu number, see “About
menu numbers” on page 16.
•The arrow mark (k) refers you to another setting list
that appears after you make the setting, or to an
operation that is carried out as a result of the setting.
When there is no arrow mark, the menu does not have
any sub-list.
[C2] REMOTE menu
Select the type of remote control.
REMOTE 1 CONFIG... : Set the address and group
number of the monitor controlled via the
REMOTE 1 (serial remote control) connector.
k[C21]
REMOTE 2 CONFIG... : Set the pin assignments for
the REMOTE 2 (parallel remote control)
connector. k[C22]
REMOTE 2: Select whether parallel remote control
will be used or not (ON or OFF).
[C21] REMOTE 1 CONFIG menu
Set the monitor address and group number.
MONITOR ADDRESS: Enter an address number.
GROUP ADDRESS: Enter a group number.
[C22] REMOTE 2 CONFIG menu
Select the REMOTE 2 connector pins for which you
want to change the function. The factory settings for
each pin are given below. k[C221]
1 PIN: CH01
2 PIN: CH02
3 PIN: EXT SYNC
4 PIN: MONO
5 PIN: SAFE AREA ON
6 PIN: unused
7 PIN: unused
8 PIN: TALLY
[C221] 1-8 PIN menu (1/2)
Assign a function to the selected pin.
CH: Select a channel number. Enter the desired
channel number with the numeric keypad.
----: Set to unused.
UNDER SCAN: Set underscan on or off.
H DELAY: Set the horizontal sync display on or off.
V DELAY: Set the vertical sync display on or off.
EXT SYNC: Set the synchronization to external sync
signals enabled or disabled.
MONO: Set the monochrome display on or off.
[C221] 1-8 PIN menu (2/2)
Assign a function to the selected pin.
R OFF: Set cutting red beams enabled or disabled.
G OFF: Set cutting green beams enabled or disabled.
B OFF: Set cutting blue beams enabled or disabled.
SAFE AREA ON: Set the safe area display on or off.
TALLY ON: Set tally signals on or off.
DEGAUSS ON: Set degaussing on or off.
POWER OFF: Set the monitor power on or off.
For the pin assignment, see “REMOTE 2 connector” in the
Location and Function of Parts on page 9.
[C2] Assigning the Remote Control Functions (SET UP 2) — REMOTE Menu
